NICR Nickel Chromium Wire Ni80Cr20 Ni70 Ni60Cr15 Nickel Chromium Resistance Wire
Product Details:
| Place of Origin: | CHN |
| Brand Name: | HMD |
| Certification: | SGS, BV, TUV, ISO |
| Model Number: | HMD-NI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Kg |
|---|---|
| Price: | Usd negotiable per Kg |
| Packaging Details: | Export standard package with polywood case or ISPM 15 stamped wooden case |
| Delivery Time: | 30 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500 Tons per Year |
|
Detail Information |
|||
| Name: | Nickel And The Alloys Pipes Fittings, Flanges | Material: | Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23 |
|---|---|---|---|
| Surface: | Bright | Application: | Aviation, Electronics, Industrial, Medical, Chemical |
| Standard: | JIS, GB, DIN, BS, ASTM, AISI | Density: | 8.902g/cm3 |
| Highlight: | NICR Nickel Chromium Wire,Ni80Cr20 chrome nickel wire,Ni60Cr15 Nickel Chromium Resistance Wire |
||
Product Description
NICR Nickel Chromium Alloy Wire Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23,Ni80, Ni70,Ni60, Ni40
Product Description:
Nichrome Wire Resistance wire(NiCr 80/20)
Nichrome Rod/Nichrome Wire (NiCr 80/20)
Chemical Composition: Nickel 80%, Chrome 20%
Condition: Bright/Acid white/Oxidied Color
Diameter: 0.018mm~1.6mm in spool, 1.5mm-8mm packing in coil, 8~60mm in rod
Chemical Composition: Nickel 80%, Chrome 20%
Condition: Bright/Acid white/Oxidied Color
Diameter: 0.018mm~1.6mm in spool, 1.5mm-8mm packing in coil, 8~60mm in rod
Nichrome Round Wire: Diameter 0.018mm~10mm
Nichrome Ribbon: Width 5~0.5mm, thickness 0.01-2mm
Nichrome Strip: Width 450mm~1mm, thickness 0.001m~7mm
Diameter: 1.5mm-8mm packing in coil, 8~60mm in rod
Grade: Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23, Ni35Cr20Fe, Ni30Cr20
Ni80, Ni70,Ni60, Ni40,
Nichrome's metallurgical structure confers them a very good plasticity when cold.
Production Standard: ASTM B603, DIN 17470, JIS C2520, GB/T1234.
Our advantage:High quality,short delivery time,small MOQ.
Characteristics:Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots.
Nichrome Ribbon: Width 5~0.5mm, thickness 0.01-2mm
Nichrome Strip: Width 450mm~1mm, thickness 0.001m~7mm
Diameter: 1.5mm-8mm packing in coil, 8~60mm in rod
Grade: Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23, Ni35Cr20Fe, Ni30Cr20
Ni80, Ni70,Ni60, Ni40,
Nichrome's metallurgical structure confers them a very good plasticity when cold.
Production Standard: ASTM B603, DIN 17470, JIS C2520, GB/T1234.
Our advantage:High quality,short delivery time,small MOQ.
Characteristics:Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots.
Chemical Composition and Main Properties of Nichrome |
||||||
| Properties Grade | NiCr 80/20 | NiCr 70/30 | NiCr 60/15 | NiCr 35/20 | NiCr 30/20 | |
| Main Chemical Composition | Ni | Balance | Balance | 55.0-61.0 | 34.0-37.0 | 30.0-34.0 |
| Cr | 20.0-23.0 | 28.0-31.0 | 15.0-18.0 | 18.0-21.0 | 18.0-21.0 | |
| Fe | ≤ 1.0 | ≤ 1.0 | Balance | Balance | Balance | |
| Max Continuous Service Temperature(oC) | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Resisivity 20oC (Ω mm2/m) | 1.09 | 1.18 | 1.12 | 1.04 | 1.04 | |
| Density (g/cm3) | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 | |
| Thermal Conductivity(KJ/m@ h@ oC) | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coefficient of Thermal Expansion(α × 10-6/oC) | 18 | 17 | 17 | 19 | 19 | |
| Melting Point( oC) | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Elongation(%) | > 20 | > 20 | > 20 | > 20 | > 20 | |
| Micrographic Structure | austenite | austenite | austenite | austenite | austenite | |
| Magnetic Property | nonmagnetic | nonmagnetic | nonmagnetic | Weak magnetic | Weak magnetic | |
Chemical Content(%)
| Grade | C | Si | Mn | P | S | Ni | Al | Fe | Cr |
| Karma | ≤0.04 | ≤0.20 | 0.5~1.05 | ≤0.010 | ≤0.010 | Bal. | 2.7~3.2 | 2.0~3.0 | 19.0~21.5 |
Physical Properties
| Grade | Density(g/cm3) | EMF vs Pt(0-100ºC)μv/ºC |
Max using Temp (ºC) |
Volume resistivity(μΩ.m) |
PPM value (×10-6/ºC) |
| Karma | 8.1 | ≤2.5 | ≤300 | 1.33±5%(20ºC) | ≤±30(20ºC) |
