Incloloy 840 800 825 Nickel Alloy Pipe Astm B619 Uns N10276 Welded Electric Heating
Product Details:
| Place of Origin: | CHN |
| Brand Name: | HMD |
| Certification: | SGS, BV, TUV, ISO |
| Model Number: | HMD-NI |
Payment & Shipping Terms:
| Minimum Order Quantity: | one piece |
|---|---|
| Price: | Usd negotiable per Kg |
| Packaging Details: | Export standard package with polywood case or ISPM 15 stamped wooden case |
| Delivery Time: | 30 Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200 Tons per Year |
|
Detail Information |
|||
| Name: | Nickel And The Alloys Pipes / Tubes | Material: | INCOLOY840,INCOLOY800,INCOLOY825,INCONEL600/601,INCONEL625,HASTELLOY C276,BT840Mo,BT800Mo |
|---|---|---|---|
| Type: | Welded Pipe | Application: | Aviation, Electronics, Industrial, Medical, Chemical |
| Standard: | JIS, GB, DIN, BS, ASTM, AISI | Density: | 8.902g/cm3 |
| Highlight: | Incloloy 825 Nickel Alloy Pipe,Nickel Alloy Pipe N10276,Astm B619 Uns N10276 Welded Electric Heating |
||
Product Description
Incloloy840 800 825 Inconel600 625 Nickel Alloy Welded Electric Heating Tubes and Pipe
Product Description:
Alloy 800, 800H, and 800HT are nickel-iron-chromium alloys with good strength and excellent resistance to oxidation and carburization in high-temperature exposure. These nickel steel alloys are identical except for the higher level of carbon in alloy 800H/HT and the addition of up to 1.20 percent aluminium and titanium in alloy 800HT. Alloy 800 was the first of these alloys and it was slightly modified into Alloy 800H. This modification was to control carbon (.05-.10%) and grain size to optimize stress rupture properties.
In heat treatment applications Alloy 800HT has further modifications to the combined titanium and aluminium levels (.85-1.20%) to ensure optimum high temperature properties. Alloy 800H/HT was intended for high temperature structural applications. The nickel content makes the alloys highly resistant to both carborisation and to embrittlement from precipitation of sigma phase.
Nickel is a chemical element with symbol Ni and atomic number 28. It is a silvery-white lustrous metal with a slight golden tinge. Nickel belongs to the transition metals and is hard and ductile. Pure nickel, powdered to maximize the reactive surface area, shows a significant chemical activity.
| Name | Nickel Alloy Weld tubing |
| Standard | ASTM B514,ASTM B515,ASTM B516,ASTM B517,ASTM B704 |
| Outer diameter | 6.0-89.0mm |
| Wall thickness | 0.3-3.0mm |
| Material | INCOLOY840,INCOLOY800,INCOLOY825,INCONEL600/601,INCONEL625,HASTELLOY C276,BT840Mo,BT800Mo |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
